THE X5
BMW X5: ENGINES &
TECHNICAL DATA
THE X5BMW X5: ENGINES & <br>TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW X5.
TECHNICAL DATA OF THE BMW X5.
Select model
- BMW X5 xDrive40i
- BMW X5 M50i
- BMW xDrive25d
- BMW X5 xDrive30d
- BMW X5 xDrive40d
- BMW xDrive45e
- BMW X5 M50d
No search result found. Please try another input
| Unladen weight EU in kg | 2,135-2,250 |
|---|---|
| Max. permissible weight in kg | 2,800-3,050 |
| Permitted load in kg | 740-875 |
| Permitted axle load front/rear in kg | 1,280-1,580/1,580-1,870 |
| Luggage capacity min. (seats up or roof down) in l | 550-650 |
| Luggage capacity max. (seats down or roof up) in l | 1,770-1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,500-3,500 |
| Trailer load 12% (braked) in kg | 2,500-3,500 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94,6/82,0 |
| Engine power in kW (hp) at 1/min | 254-250 (333-340)/5,500-6,250 - 5,500-6,500 |
| Engine torque (Nm) at 1/min | 450/1,600-4,800 - 1,500-5,200 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 241-243 |
|---|---|
| Acceleration 0–100 km/h in s | 5.9-5.5 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 10.9 |
|---|---|
| Extra–urban in l/100 km | 8.3-8.2 |
| Combined in l/100 km | 9.2 |
| CO2 combined emissions in g/km | 211-210 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 83 |
| Tyre dimensions front | 265/50 R19 110 W XL |
|---|---|
| Tyre dimensions rear | 265/50 R19 110 W XL |
| Wheel dimensions and material front | 9 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 9 J x 18 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,325-2,335 |
|---|---|
| Max. permissible weight in kg | 2.995 |
| Permitted load in kg | 735-745 |
| Permitted axle load front/rear in kg | 1,430/1,645 |
| Luggage capacity min. (seats up or roof down) in l | 650 |
| Luggage capacity max. (seats down or roof up) in l | 1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,700-3,500 |
| Trailer load 12% (braked) in kg | 2,700-3,500 |
| Cylinders/valves | 8/4 |
|---|---|
| Capacity in ccm | 4.395 |
| Stroke/bore in mm | 88.3/89.0 |
| Engine power in kW (hp) at 1/min | 390 (530)/5,500-6,000 |
| Engine torque (Nm) at 1/min | 750/1,800-4,600 |
| Compression ratio : 1 | 10.5 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.3 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 15.2 |
|---|---|
| Extra–urban in l/100 km | 9.4 |
| Combined in l/100 km | 11.5 |
| CO2 combined emissions in g/km | 263 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 83 |
| Tyre dimensions front | 275/40 R21 107 Y XL |
|---|---|
| Tyre dimensions rear | 315/35 R21 111 Y XL |
| Wheel dimensions and material front | 9.5 J x 21 inches, light-alloy |
| Wheel dimensions and material rear | 10.5 J x 21 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,145-2,245 |
|---|---|
| Max. permissible weight in kg | 2,820-2,940 |
| Permitted load in kg | 750-770 |
| Permitted axle load front/rear in kg | 1,285-1,300/1,610-1,785 |
| Luggage capacity min. (seats up or roof down) in l | 550-650 |
| Luggage capacity max. (seats down or roof up) in l | 1,770-1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,700-2,700 |
| Trailer load 12% (braked) in kg | 1,700-2,700 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1.995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 155-170 (211-231)/4,400 |
| Engine torque (Nm) at 1/min | 450/1,500-3,000 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 216-222 |
|---|---|
| Acceleration 0–100 km/h in s | 7.8-7.5 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 7.2-7.0 |
|---|---|
| Extra–urban in l/100 km | 6.7-6.4 |
| Combined in l/100 km | 6.8-6.7 |
| CO2 combined emissions in g/km | 180-177 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 80 |
| Tyre dimensions front | 265/50 R19 110 W XL |
|---|---|
| Tyre dimensions rear | 265/50 R19 110 W XL |
| Wheel dimensions and material front | 9 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 9 J x 18 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,260-2,185 |
|---|---|
| Max. permissible weight in kg | 3,090-2,860 |
| Permitted load in kg | 750-905 |
| Permitted axle load front/rear in kg | 1,320-1,340/1,615-1,870 |
| Luggage capacity min. (seats up or roof down) in l | 550-650 |
| Luggage capacity max. (seats down or roof up) in l | 1,770-1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,700-3,500 |
| Trailer load 12% (braked) in kg | 1,700-3,500 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2.993 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 210 (286)/4,000 |
| Engine torque (Nm) at 1/min | 650/1,500-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 235 |
|---|---|
| Acceleration 0–100 km/h in s | 6.3-6.1 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 7.8 |
|---|---|
| Extra–urban in l/100 km | 6.3 |
| Combined in l/100 km | 6.9 |
| CO2 combined emissions in g/km | 180 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 80 |
| Tyre dimensions front | 265/50 R19 110 W XL |
|---|---|
| Tyre dimensions rear | 265/50 R19 110 W XL |
| Wheel dimensions and material front | 9 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 9 J x 18 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,360-2,275 |
|---|---|
| Max. permissible weight in kg | 3,170-2,940 |
| Permitted load in kg | 885-740 |
| Permitted axle load front/rear in kg | 1,375-1,395/1,635-1,885 |
| Luggage capacity min. (seats up or roof down) in l | 550-650 |
| Luggage capacity max. (seats down or roof up) in l | 1,770-1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,500-3,500 |
| Trailer load 12% (braked) in kg | 2,500-3,500 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2.993 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 250 (340)/4,400 |
| Engine torque (Nm) at 1/min | 700/1.750-2.250 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 245 |
|---|---|
| Acceleration 0–100 km/h in s | 5.6-5.5 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 8.1 |
|---|---|
| Extra–urban in l/100 km | 6.5 |
| Combined in l/100 km | 7.1 |
| CO2 combined emissions in g/km | 186 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 80 |
| Tyre dimensions front | 265/50 R19 110 W XL |
|---|---|
| Tyre dimensions rear | 265/50 R19 110 W XL |
| Wheel dimensions and material front | 9 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 9 J x 18 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,510 |
|---|---|
| Max. permissible weight in kg | 3,150 |
| Permitted load in kg | 715 |
| Permitted axle load front/rear in kg | 1,390/1,810 |
| Luggage capacity min. (seats up or roof down) in l | 500 |
| Luggage capacity max. (seats down or roof up) in l | 1,720 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,700 |
| Trailer load 12% (braked) in kg | 2,700 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2.998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 155-210 (211-286)/5,000-6,000 - 5,000-6,500 |
| Engine torque (Nm) at 1/min | 450/1,600-3,500 - 1,500-3,500 - 1,600-3,000 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 235 |
|---|---|
| Acceleration 0–100 km/h in s | 5.6 |
| Top speed fully electric in km/h | 135 |
| Urban in l/100 km | - |
|---|---|
| Extra–urban in l/100 km | - |
| Combined in l/100 km | 2.5 |
| CO2 combined emissions in g/km | 56 |
| Electricity consumption combined in kWh/100km | 25.7 |
| Tank capacity, approx. in l | 69 |
| Tyre dimensions front | 265/50 R19 110 W XL |
|---|---|
| Tyre dimensions rear | 265/50 R19 110 W XL |
| Wheel dimensions and material front | 9 J x 19 inches, light-alloy |
| Wheel dimensions and material rear | 9 J x 19 inches, light-alloy |
| Electric range in km | 77 |
|---|---|
| Growth capacity of lithium–ion battery in kWh | 24.0 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | 5.0-4.9 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | 6.8-6.6 |
| Electric engine power kW (HP) at 1/min | 83 (113)/3,170 |
|---|---|
| Electric Engine torque (Nm) at 1/min | 265/100-2,500 |
| Combined power kW (HP) | 290 (394) |
|---|---|
| Combined torque Nm | 600 |
| Unladen weight EU in kg | 2,425-2,350 |
|---|---|
| Max. permissible weight in kg | 3,160-3,010 |
| Permitted load in kg | 735-810 |
| Permitted axle load front/rear in kg | 1,395-1,405/1,670-1,865 |
| Luggage capacity min. (seats up or roof down) in l | 550-650 |
| Luggage capacity max. (seats down or roof up) in l | 1,770-1,870 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,700-3,500 |
| Trailer load 12% (braked) in kg | 2,700-3,500 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2.993 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 294 (400)/4,400 |
| Engine torque (Nm) at 1/min | 760/2,000-3,000 |
| Compression ratio : 1 | 16.0 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 5.3-5.2 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | 8.6-8.4 |
|---|---|
| Extra–urban in l/100 km | 7.3 |
| Combined in l/100 km | 7.8-7.7 |
| CO2 combined emissions in g/km | 204-202 |
| Electricity consumption combined in kWh/100km | - |
| Tank capacity, approx. in l | 80 |
| Tyre dimensions front | 275/40 R21 107 Y XL |
|---|---|
| Tyre dimensions rear | 315/35 R21 111 Y XL |
| Wheel dimensions and material front | 9.5 J x 21 inches, light-alloy |
| Wheel dimensions and material rear | 10.5 J x 21 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (HP) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (HP) | - |
|---|---|
| Combined torque Nm | - |
Fuel consumption, electricity consumption and CO2 emissions of the BMW X5.
BMW X5 xDrive40i:
Fuel consumption in l/100 km (combined): 9.2
BMW X5 xDrive45e:
Fuel consumption in l/100 km (combined): 2.5
European model shown. *BMW AG predicted estimated range (based on WLTP methodology), horsepower and acceleration. Official EPA test results are not yet available. Range may vary based on driving habits and other factors.
** The My BMW App is optimized for BMW vehicles from 2016 model year and newer in conjunction with the option ConnectedDrive Services and a compatible smartphone. Available apps and services are subject to change, may vary by location or other factors. May require additional services, plans, subscriptions and vehicle options, and may only be operable in conjunction with certain smartphones and operating systems (smartphone not provided). Not all apps or services may be available for all BMW models.
